Dimlux DIMLUX XTREME LED 500W (+NIR)

Dimlux DIMLUX XTREME LED 500W (+NIR)

PhytoVegSpec® Indoor

Light Output 1500 µmol/s
Light Output Total (PPF 350-800nm)
1571 µmol/s
System Efficacy
2.81 µmol/J @ 230V AC
System Efficacy Total (PPE 350-800nm)
2.91 µmol/J @ 230V AC



Specifications - Xtreme Series 500w LED
Light Output (PPF) 1500 µmol/s
PAR Photon Efficacy (400-700nm) 2.81 µmol/J @ 240V AC
Total Photon Efficacy (350-800nm) 2.91 µmol/J @ 240V AC
AC Input Power 540W @ 230-240V AC
AC Input Voltage 120-277V AC, 50/60Hz
Beam Angle 90° × 120°
Optics Patented Deep Penetration Ultra High Transmittance Lens
Auxiliary Light Patented Light Pipe Multi Color 65k
Proximity sensor Doppler Radar
Mounting Height Above Canopy 20-50 cm / 7.8-19.7 in
Thermal Management Passive
Max. Ambient Temperature 40°C / 105°F
Control By Maxi Controller or Internal Controller
Smartports (3x) Interlink, Plant Temperature Sensor, Light Sensor
Display For Spectrum and GUI 1.54" 65k Color IPS
Total Harmonic Distortion (THD) < 10%
Lifetime L90 > 50,000h
IP Rating IP65
Certifications CE, UL 8800, UL 1598 Wet Location, DLC
Warranty 5 Year Standard
Measurements 32.8" x 31.9" x 2.2"
